Leoxz XF1 Sport-USB Wheel

TECHNICAL SPECIFICATIONS

• The 275 mm diameter polyurethane grip, produced with high-precision molds, has a special coating on its surface, and its delicate texture satisfies various driving needs.
• The back cover and paddles are machined using CNC technology and coated with black anodization for optimal appearance and extended durability.
• The front panel is made of 5mm 3K carbon fiber, and the paddles are made of 3mm 3K carbon fiber.
• 18 RGB LEDs customizable through SimHub.
• 4.3″ IPS screen with a resolution of 480×272 pixels and a refresh rate of 60fps.
• 15 built-in dashboards containing various telemetry signals.
• 16 reliable buttons and 3 pushable encoders.
• Included 2 anodized metal blue rotary knobs.
• Comes with a standard magnetic gear shift paddle and clutch paddles.
• Clutch paddles can be set to clutch point mode, axis mode, and button mode.
• All paddles use contactless Hall sensors for extended durability.
• Robust and reliable USB-XS9 interface with locking mechanism.
• 70mm diameter QR mounting hole.
• Can only be connected via USB for wired connection.

COMPATIBLE HARDWARE

• Simagic Alpha, Alpha Mini, Alpha U
• Simucube SC1, SC2 (QR to be purchased separately)
• Moza R16, R9, R5
• Asetek Invicta, Forte DD (QR to be purchased separately)
• Fanatec DD1, DD2, CSW, CSL DD, DD Pro, ClubSport DD (Base torque must be unlocked with PHUB or Leoxz Fanatec QR, while connecting via USB)

SOFTWARE

• PC only with SimHub and SimBridge
• SimHub for obtaining telemetry data
• SimBridge is used to receive SimHub data and send to XF1

DISCOVER THE LEOXZ XF1

WHAT’S INCLUDED?

• XF1-USB sports steering wheel (optional quick release)
• USB-XS9 cable
• Custom stickers
• M3 hex key
• Nylon tweezers

DOWNLOADS

XF1 Sport-USB Manual
Firmware
SimBridge
SimHub
