- Compatible platforms
- PC
- Motor technology
- Direct Drive
- Peak torque
- 12 N·m
- Peak power
- 216 W
- Maximum rotation
- 90–2700°
- Housing
- Aerospace-grade aluminium alloy
- Colour
- Black
- Power Supply
- 110–220V AC → 36V DC
- USB refresh rate
- 1000 Hz
- Base indicator light
- Yes
- Mobile app
- Yes (MOZA Pit House)
- Quick release
- MOZA Quick Release
- Connections
- Power, USB, Pedals, Dash, Shifter, Handbrake, E-stop
- Mounting
- 4-hole bottom mounting; side mounting supported; optional desk clamp
- Emergency Stop
- Optional
- Firmware update
- Yes
- Dimensions (W×D×H)
- 225.87 × 156.68 × 123.99 mm
- Weight
- 7.5 kg
- Diameter
- 300 mm, GT style
- Weight
- 2.6 kg
- Dimensions (W×D×H)
- 300 × 120 × 165 mm
- Paddle material
- Aluminium alloy
- Shift paddles
- 2 magnetic
- Clutch paddles
- 2, combined axis / independent axis / button modes
- Paddle sensor
- Contactless Hall
- Buttons
- 10 illuminated short-travel (RGB, 0.25 mm travel, 8 colours)
- Joystick
- 2 push-to-click
- Thumb encoders
- 2 with 20 positions
- Rotary encoders
- 3 with 12 positions
- LED
- 10 high-brightness, 8 customisable colours
- RPM LEDs
- Fully adjustable via MOZA Pit House
