- Type
- Direct Drive
- Peak torque
- 9 Nm
- Peak power
- 180 W
- Rotation
- 90–2700° adjustable
- Motor
- High-performance servo (18 slots / 16 poles)
- Encoders
- 21-bit magnetic (2,097,152 steps/rev)
- Material
- Aerospace-grade aluminium alloy
- USB refresh rate
- 1000 Hz
- Cooling
- Smart temperature monitoring and active cooling
- Power Supply
- 110–220 V AC → 36 V DC
- Connections
- Power, DC, Pedals, E-stop, USB, Dash, Shifter, Handbrake
- Quick release
- MOZA Quick Release
- Mounting
- 4 bottom holes; optional desk clamp and side mount
- Software
- MOZA Pit House, mobile app and online firmware updates
- Dimensions (W×D×H)
- 240 × 157 × 124 mm
- Diameter
- 300 mm, GT style
- Weight
- 2.6 kg
- Dimensions (W×D×H)
- 300 × 120 × 165 mm
- Paddle material
- Aluminium alloy
- Shift paddles
- 2 magnetic with contactless Hall sensor
- Clutch paddles
- 2, combined axis / independent axis / button modes
- Buttons
- 10 illuminated short-travel RGB buttons (0.25 mm, 8 colours)
- Joystick
- 2 push-to-click
- Thumb encoders
- 2 with 20 positions
- Rotary encoders
- 3 with 12 positions
- Lighting
- 10 high-brightness LEDs (8 colours), adjustable with telemetry via MOZA Pit House
- Connection
- Industrial slip ring
- Quick release
- MOZA Quick Release
- Compatibility
- All MOZA wheelbases and third-party wheelbases
- Software
- MOZA Pit House
